FR4 Double Sided PCB Board HASL LF Finished Surface Quick Turn PCB Fabrication

Name: FR4 Double Sided PCB Board HASL LF Finished Surface Quick Turn PCB Fabrication
Brand: JINGXIN
Price: 1 USD

FR4 Double Sided PCB Board HASL LF Finished Surface Quick Turn PCB Fabrication Manufactures

Brand Name : JINGXIN

Model Number : JX18112740

Certification : ISO9001 / TS16949 / IPC / ROHS / UL

Place of Origin : CHINA

MOQ : 1 PC

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30000pcs per day

Delivery Time : 5-7 days

Packaging Details : ESD Bag

Color : Blue

Rogers High Frequency PCB : China Rogers Pcb Printed Circuit Board

Board Size : 200*100mm

Panel : 1

Number Of Layers : 2

Base Material : Rogers+FR4 Material

Contact Now

FR4 Double Sided PCB Board HASL LF Finished Surface Quick Turn PCB Fabrication

Quick detail:

Origin:China	Special: FR4 Material
Layer:2	Thickness:1.6mm
Surface: HASL-LF	Hole:0.8

Specification:
FR-4 material is a fire code rating, represents a material specification is meant a resin material through the combustion state must be self-extinguishing, it is not a material name, but a material grade. So now FR-4 grade material is typically used in circuit boards, there are many species, but most are based on the so-called four-function (Tera-Function) plus epoxy filler (Filler) and glass fiber made composite materials.

Typical Applications

Cellular Base Station Antennas and Power Amplifiers
Microwave point to point (P2P) links
Automotive Radar and Sensors
low dielectric loss
Ballast, lights, navigation
The stability of the dielectric constant
An extremely low water imbibition
IT industry,Keyboard products

FR-4 epoxy glass Burkina board, based on epoxy resin as the binder, the electronic-grade glass fiber cloth as a reinforcing material-based substrate. Its bonding sheet and the inner core thin CCL is an important base of manufacturing a multilayer printed circuit board.

Parameter:

o	Item	Data
1	Layer:	1 to 24 layers
2	Material type:	FR-4, CEM-1, CEM-3, High TG, FR4 Halogen Free, Rogers
3	Board thickness:	0.20mm to 3.4mm
4	Copper thickness:	0.5 OZ to 4 OZ
5	Copper thickness in hole:	>25.0 um (>1mil)
6	Max. Board Size:	(580mm×1200mm)
7	Min. Drilled Hole Size:	4mil(0.1mm)
8	Min. Line Width:	3mil (0.075mm)
9	Min. Line Spacing:	3mil (0.075mm)
10	Surface finishing:	HASL / HASL lead free, HAL, Chemical tin, Chemical Gold, Immersion Silver/Gold, OSP, Gold plating
11	Solder Mask Color:	Green/Yellow/Black/White/Red/Blue
12	Shape tolerance:	±0.13
13	Hole tolerance:	PTH: ±0.076 NPTH: ±0.05
14	Package:	Inner packing: Vacuum packing / Plastic bag,Outer packing: Standard carton packing
15	Certificate:	UL,SGS,ISO 9001:2008
16	Special requirements:	Buried and blind vias+controlled impedance +BGA
17	Profiling:	Punching, Routing, V-CUT, Beveling

Features

• High Thermal Performance
 Tg: 180°C (DSC)
 Td: 340°C (TGA @ 5% wt loss)
 Low CTE for reliability
• T260: 60 minutes
• T288: 30 minutes
• RoHS Compliant
• UV Blocking and AOI Fluorescence
 High throughput and accuracy during PCB
fabrication and assembly
• Superior Processing
 Closest to conventional FR-4 processing
• Core Material Standard Availability
 Thickness: 0.002″ (0.05 mm) to 0.125″
(3.2 mm)
 Available in full size sheet or panel form
• Prepreg Standard Availability
 Roll or panel form
 Tooling of prepreg panels available
• Copper Foil Type Availability
 Standard HTE Grade 3
 RTF (Reverse Treat Foil)
• Copper Weights
 ½, 1 and 2 oz (18, 35 and 70 μm) available
 Heavier copper available upon request
 Thinner copper foil available upon request
• Glass Fabric Availability
 Standard E-glass
 Square weave glass fabric available
 Spread glass fabric available
• Industry Approvals
 IPC-4101C /21 /24 /26 /97 /98 /99 /101 /126
 UL - File Number E41625 as PCL-FR-370HR
 Qualified to UL's MCIL Program

Rogers material in stock:

Brand	Model	Thickness(mm)	DK(ER)
F4B	F4B	0.38	2.2
	F4B	0.55	2.23
	F4B	0.225,0.3,0.5,08,1,1.2,1.5,2,2.5,3.0	2.65
	F4Bk	0.8,1.5	2.65
	F4B	0.8	3.5
	FE=F4BM	1	2.2
Rogers	RO4003	0.254 0.508,0.813,1.524	3.38
	RO4350	0.254 0.508,0.762,1.524	3.5
	RO5880	0.254.0.508.0.762	2.2
	RO3003	0.127,0.508,0.762,1.524	3
	RO3010	0.635	10.2
	RO3206	0.635MM	10.2
	R03035	0.508MM	3.5
	RO6010	0.635MM, 1,27MM	10.2
